Welded Mesh Panels for Fencing, Construction & Industrial Applications

Welded mesh panels are manufactured by resistance welding steel wires at uniform intersections to form rigid, flat panels. Common materials include low-carbon steel, galvanized steel, and stainless steel for enhanced corrosion resistance. They are widely used in fencing systems, concrete reinforcement, partitions, cages, and safety barriers. Welded mesh panels are classified by wire diameter, mesh opening size, panel dimensions, and surface treatment such as black, electro-galvanized, or hot-dipped galvanized finishes, meeting construction, agricultural, and industrial requirements.

Specifications

• Material: Low-carbon steel Q195/Q235, galvanized steel wire, stainless steel 304/316.
• Wire Diameter Range: 2.0–12.0 mm for light fencing, standard enclosures, and heavy-duty reinforcement.
• Mesh Opening Size: 25 × 25 mm to 200 × 200 mm for security fencing, cages, and partitions.
• Panel Width: 1.0–2.5 m for easy handling, transport, and installation.
• Panel Length: 2.0–6.0 m with common lengths of 2.0 m, 2.5 m, and 3.0 m.
• Surface Finish Options: Black, electro-galvanized, hot-dipped galvanized after welding.
• Weld Strength: Resistance-welded joints with typical shear strength of 1.2–1.5 kN.
• Tensile Strength: Steel wire tensile strength of approximately 350–550 MPa.
• Zinc Coating Weight: Galvanized coatings from 40–300 g/m² for corrosion protection.
• Edge Treatment: Cut flush, trimmed, or framed panel edges.
• Panel Weight: Approximately 5–60 kg per panel depending on size and wire diameter.

Features

• Rigid welded structure provides high strength and dimensional stability
• Uniform mesh openings ensure consistent quality and precise sizing
• Multiple material options including low-carbon steel, galvanized steel, and stainless steel
• Corrosion-resistant finishes such as electro-galvanized and hot-dipped galvanized
• Easy installation and handling due to flat panel form
• Long service life with low maintenance in indoor and outdoor applications

Applications

• Fencing systems for residential, commercial, and industrial security
• Construction reinforcement for walls, floors, and concrete structures
• Agricultural enclosures including livestock fencing and animal cages
• Industrial safety barriers and machine guards
• Infrastructure and landscaping for partitions, retaining systems, and protective panels

Welded mesh panels are widely used where strength, durability, and installation efficiency are required across construction, fencing, agriculture, and industrial projects.
